MEYRA NANO S 1.157

Features

For permanent and long-term care

For paraplegic care

Very well suited for a wide range of medical conditions, including the severely afflicted

Users with loss of lower extremity function (lateral transfer, hand rim propulsion)

For neurological disorders

For users with some remaining walking and standing ability (sit to stand transfer)

Features:

• The rigid frame design means less flex in the frame, making the chair easier to push and more responsive—perfect for sport.
• Rigid frame chairs are lighter too. With fewer parts such as crossbars and folding joints, the Nano is easier to put in the car yourself.
• The Nano X’s rigid frame design is lighter than a folding chair, so it’s easier to put in a car yourself.
• Lightweight magnesium wheels are available in metallic blue, red, orange, black and white.
• Solid rubber castor wheels with aluminium rims are optionally available in trendy Xtrend colours.
• Designed with an open frame and clear lines, the minimalistic look doesn’t get in the way of your personal style.

Benefits:

• Maximum smoothness of ride and low tare weight encourage independence of the user
• Fine adjustment of the back element, seat and suspension enable adaptation to changes in function and individual user requirements
• Extensive range of equipment for long-term users
• Very well suited for a wide range of medical conditions, including the severely afflicted
• Users with loss of lower extremity function (lateral transfer, hand rim propulsion)

Technical Details:

• Total width with 0° wheel camber Seat width +170
• Back strap height adjustable by +/- +/- 15
• Seat width 320 340 360 380 400 420 440 460 480
• Width, ready to move 480 500 520 540 560 580 600 620 640 660 680
• Seat depth 380 / 400 / 420 / 440 / 460 / 480 / 500
• Seat height front / rear 450 to 530 / 360 to 510
• Total height Seat height rear + back height
• Back height variable from 250 to 450 + - 15 mm
• Lenght with footrest 720 - 920 (depending on frame length, wheel size and axle position)
• Compact frame, short 720 - 800
• Compact frame, medium 760 - 840
• Compact frame long 800 -880
• Standard frame short 760 - 840
• Standard frame medium 800 - 880
• Standard frame long 840 - 920
• max. User weight 130 kg
• Empty weight from 9 kg
• Permissible total weight 145 kg
• Transport weight from 6.5
• Drive wheel 600 (24")
• Drive wheel 635 (25")
• Drive wheel 660 (26")
• Brake test according to STANDARD
